ECHO SOLO / LIGHT GRAY

The Echo Solo features a welded steel frame with Cromoly front triangle for fine handling and great looks. Equipped with a stylish Creme alluminium crankset and 16-speed Shimano drivetrain controlled by modern Shimano Claris STI shifters. Clearance for up to 37mm tyres with fenders. You will find some nice touches such as polished rims and a classic 1” quill stem. Front rack compatible with a comfy Creme saddle. Finished in a high-end multi layer gloss paint in light gray. This bike is the ideal choice for anyone who wants to get a first taste of how good road cycling can be.

SPEC
COLOR
Creme are available! Want to join the Creme family? Let us know which bike you're interested in and we'll direct you to the nearest dealer or distributor.
Ask about availability
Close

Sizing|Tech

SIZES: S / M / L
RECOMMENDED RIDER HEIGHT (CM):
 160-168 / 168-177 / 177-190
SEAT TUBE LENGTH (MM): 510 / 550 / 605
EFFECTIVE TOP TUBE (MM): 540 / 561 / 575
CHAINSTAY LENGTH (MM): 425
HEADTUBE ANGLE (°): 72 / 73 / 74
SEAT TUBE ANGLE (°): 74 / 73 / 73
HEADTUBE LENGTH (MM): 110 / 130 / 170
WHEELBASE (MM): 989 / 1000 / 1025
BOTTOM BRACKET DROP (MM): 70
FORK OFFSET (MM): 45
AXLE TO CROWN (MM): 367

Frame: lugged steel frame
Sizes: MEN: S, M, L LADY: S/M, M/L
Fork: cromoly steel fork, lugged, 1", with invest cast crown
Handlebar: *flat bar width: 560mm, rise: 15mm, backsweep: 62, bar bore: 25,4mm drop bar, width: 420mm, barbore: 26,0mm, drop: 120mm, reach: 75mm
Grips: Velo bar tape
Stem: aluminium quill stem, 100mm, 80mm*, high polish
Saddle: Creme microsuede cover
Seatpost: aluminium 26,6mm
Brake front: Promax caliper, dual pivot
Brake rear: Promax caliper, dual pivot
Shifters: Shimano Claris R2000 STI / Sunrace SLM96 R8 thumb shifters*
Crankset: Creme aluminium 42t, 170mm
Bottom bracket: square taper, 68mm shell
Deraileur front: Shimano Claris
Deraileur rear: Shimano Claris short cage
Cassette: Falcon 11-28, 8-speed
Chain/belt: KMC X8
Hub front: aluminium road hub, sealed bearings, 32H, QR
Hub rear: aluminium road hub, sealed bearings, 32H, QR
Rims: aluminium doublewall 700C, road racing
Tyres: WTB Expanse 700x32C
Carrier / Basket: *chrome plated front rack
Mudguards: ---
Headset: threaded, 1”
Light front: ---
Light rear: ---
Pedals: FP-980AZU
Spokes: stainless steel
Stand: ---
Additional: stylish bell
Weight: 10,6kg 11kg*
Seat Tube Diameter: 28,6 mm
Seatpost diameter: 26,6/350mm
Pedal thread: 9/16"
Stem clamp size: bar bore 26mm, dia 22,2mm,
Max tyre: 37-622, 700X35C
Electric Drive: ---
Battery: ---

Please note that production bicycles may slightly differ in specifications and/or color from those shown on this website. All listed specifications are subject to change without notice.


Intended use: ROAD RIDING
